Model specifications
| Model | HPL-000355 |
|---|---|
| Material | Iron Curved Frame + White Silicone Diffuser LED Bar + Brown Leather Strap Suspension + Black Powder-Coated Steel Canopy |
| Finish | A wide gentle 'smile' arc: a black iron frame curves from one ceiling point down and back up to a second ceiling point; a continuous white silicone LED bar runs along the inside of the arc; brown leather straps span across the curve at intervals to hold the LED bar against the iron frame |
| Dimensions | Span 1.0m / 1.2m / 1.5m / 1.8m / 2.0m (chord between two ceiling rosettes); arc rises ~25cm above the chord; canopy Dia. 10cm x 2 |
| Light source | Built-in LED Strip inside silicone diffuser (integrated, not user-replaceable) |
| Power | 12W / 16W / 20W / 24W / 28W (1.0m / 1.2m / 1.5m / 1.8m / 2.0m) |
| Input voltage | AC 110-240V |
| Colour temperature | 3000K Warm White |
| Dimming | TRIAC dimmable on request |
| IP rating | IP20 – indoor use only |
| Bulbs included | Yes – integrated LED light source |
| Beam Angle | 180° downward through silicone diffuser |
Configuration references
The specifications above describe this model as a whole; they do not establish separate technical ratings for every option. Confirm the required size, finish, light source and electrical version in your quotation.
| Configuration SKU | Listed configuration | Size / combined size option |
|---|---|---|
| HPL-000355-01 | Span: Span 1.0m (12W) | Span 1.0m (12W) |
| HPL-000355-02 | Span: Span 1.2m (16W) | Span 1.2m (16W) |
| HPL-000355-03 | Span: Span 1.5m (20W) | Span 1.5m (20W) |
| HPL-000355-04 | Span: Span 1.8m (24W) | Span 1.8m (24W) |
| HPL-000355-05 | Span: Span 2.0m (28W) | Span 2.0m (28W) |
Product questions
What light source is specified for HPL-000355?
Built-in LED Strip inside silicone diffuser (integrated, not user-replaceable). Confirm the selected configuration and destination-market requirements when requesting a quotation.
Which configurations can I enquire about for HPL-000355?
There are 5 listed configuration references under this model. Size or combined size options include Span 1.0m (12W); Span 1.2m (16W); Span 1.5m (20W). The table lists the complete configuration references; confirm the final dimensions and finish for the option you select.
Enquire about HPL-000355
Include the configuration SKU, required quantity, finish and destination market in your request.
